Tripp Lite 1ft HDMI Active Signal Extender Equalizer Cable HDMI 60Hz M-F 1' ->  -> May Require Up to 5 Business Days to Ship -> May Require up to 5 Business Days to Ship - SystemsDirect.com

Tripp Lite 1ft HDMI Active Signal Extender Equalizer Cable HDMI 60Hz M-F 1' -> May Require up to 5 Business Days to Ship

  • $ 58.99

We currently have 223 in stock.
SKU: MPN: B123-001-60 UPC:
Product Description
Tripp Lite's B123-001-60 HDMI Signal Extender increases the distance a 1080p @ 60Hz(or 1920 x 1200) signal can be transmitted beyond the recommended 16 ft.(5 m.). It supports computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p @ 60Hz, at a maximum distance of 125 ft. from the source. Use P568-Series HDMI cables in most applications. When extending a 1080p @ 60Hz(or 1920 x 1200) signal more than 75 ft., use cable made with 24Awg wiring, such as the P568-100-HD.(Lengths over 100 ft. are available from Tripp Lite as a custom order) 24Awg HDMI cable is also needed when extending a 3D signal more than 50 ft.. A 3D signal can be extended up to 125 ft. using 24Awg HDMI cable. Simply connect the longer cable between the source and the B123-001-60, and the built-in cable between the adapter and the monitor/TV. Software or drivers are not required. HDCP compliant. Compliant with the Federal Trade Agreements Act(TAA) for GSA Schedule purchases.
  • The B123-001-60 has been designed for use with Tripp Lite P568-Series HDMI cables. To ensure maximum distance and performance, it is recommended that you use Tripp Lite P568-Series HDMI cabling. For distances over 75-ft, 24AWG cable such as Tripp Lite's P568-100-HD is required.
  • Although most installations will not require power, a Micro USB port is provided in the event power is needed. Using a Micro USB cable(such as Tripp Lite's UR05C-Series), connect the Micro USB port to a USB wall charger, the USB port on your monitor, or the USB port on a computer.

  • When extending a 1080p @ 60Hz (or 1920 x 1200) signal more than 75 ft., use cable made with 24Awg wiring, such as the P568-100-HD
  • Supports DTS-HD, Dolby True HD and 7.1 Channel Surround Sound Audio
  • Extend a 1080p @ 60Hz (or 1920 x 1200) HDMI signal up to 125 ft. from the source
  • Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases
  • 24Awg HDMI cable is also needed when extending a 3D signal more than 50 ft.. A 3D signal can be extended up to 125 ft. using 24Awg HDMI cable
