Mellanox 25Gb/s Optical Transceiver

Mellanox 25Gb/s Optical Transceiver

  • $ 127.99

We currently have 74 in stock.
Product Description
Mellanox® MMA2P00-AS is a, pluggable SFP28 optical transceiver, designed for use in 25Gb/s Ethernet. This module incorporates Mellanox integrated circuit technology, in order to provide high performance at low power. The transceiver operates over a pair of multi-mode (MMF) fibers, using a nominal wavelength of 850 nm, and is SFF-8402 compliant.

The MMA2P00-AS has a standard SFP28 connector on the electrical side towards the host system supporting CAUI-1. The optical interface is composed of two optical channels/fibers, one in each direction, intended for a multi-mode optical cable connected via standard LC connectors. Each channel/fiber operates at signaling rates up to 25.78125 GBd.

Rigorous production testing ensures the best out-of-the-box installation experience, performance, and durability.
  • 25G to 10G rate selection by turning off CDR
  • SFF-8472 compliant I2C management interface
  • IEEE 802.3 10GBASE-SR compliant
  • RoHS6 compliant
  • IEEE 802.3 25GBASE-SR compliant
  • Hot pluggable
  • Up to 100m on OM3 at 10Gb/s
  • Class 1 laser safety
  • Up to 100m on OM4 and 70m on OM3 multimode fiber at 25Gb/s
  • BER better than 1E-15
  • 3.3V power supply
  • SFP28 power level 1
  • SFF-8402 compliant
  • Selectable retiming
  • Programmable Rx output emphasis
  • Programmable Tx input equalizer
  • Up to 26Gb/s data rate
