Specifications are provided for reference and are based on testing the ZT411™ printer using genuine Zebra® supplies. Results may vary in actual application settings or when using other-than-recommended Zebra supplies. Zebra recommends always qualifying any application with thorough testing

Standard Features | Printing

Thermal transfer and direct thermal printing
Thin film printhead with E3™ Element Energy™ Equalizer for superior print quality
203 dpi print resolution (8 dots / mm)
Print speed per second up to 14" (356 mm / second)

Communication

USB 2.0, high speed
RS-232 Serial (RS-232C with DB9F connector; Configurable baud rate (2400 - 115,200kB), parity, and data bits. Stop bits at 1 or 2; Software (XON/XOFF), hardware (DTR/DSR or RTS/CTS) communication handshake protocols)
10/100 Ethernet: Supports networks internally integrated option that enables the use of Webview and Alert features
Bluetooth® 4.1 (including Apple®)
Dual USB Host

Operation

4.3-inch color touch display with intuitive menu for quick operation and settings management
Bi-colored status LEDs for quick printer status
ARM Cortex A7 processor
256 MB RAM memory (8 MB User Available)
512 MB Flash memory (64 MB User Available)
Print Touch™ application
Link-OS®-enabled
Auto-switching 100-240V power supply
ENERGY STAR® qualified
Printhead element out detection

Media Support

Dual media sensors - transmissive and reflective
3" media supply hanger
Auto calibration when printer is turned on or when printhead is closed

Design

Easy, side-loading metal print mechanism
Tool-less printhead and platen replacement
Metal media cover with enlarged clear viewing window
Robust-gold user touch points indicating key adjustments
Bi-fold media door decreasing overall operating space by 35%

Firmware

Resident ZPL®, ZPL II® and EPL™ programming languages, selectable through software or front panel
XML-Enabled Printing - allows XML communications for barcode label printing eliminating license fees and printer server hardware while lowering customization and programming costs

A smart and inexpensive solution to print temporary documents
203 maximum print resolution (dpi) for better reliance and added usability
Produce high-quality documents with this monochrome printer to increase your productivity
Delivers high-speed, hassle-free labeling solution for your business needs
Optimize your workflows by sharing the resources of the printer via Ethernet connectivity
Enjoy the freedom of wireless connectivity. With Wi-Fi, you will get things done faster.
4.09" maximum label width for dependable, desired results
39" maximum label length for your convenience and feasible usability
Supports label media type for better reliance and maximum usability
Direct Thermal Printer with industrial application/usage provides reliable, feasible printing solution
